My earlier attempts with Machine Learning
When I started programming, I saw all sort of videos about training neural networks to play games. Y’know, those “AI learns to play name of game” videos that use some black-box optimization techniques like Genetic Algorithm (GA) to optimize the network and gradually gets better at playing that game. The most iconic video was probably SethBling’s MarI/O - Machine Learning for Video Games (which, not gonna lie, was much simpler than what I recalled). This technique originates from an old paper, Evolving Neural Networks through Augmenting Topologies, which I have just seen right now after checking out the SethBling video’s description. The main idea is to prepare some neural network topology, and the standard procedure of GA is used to furthermore optimize this model via tweaking its parameters.
GA is inefficient, to say the least. Neural networks have a quite simple structure, it’s just the scale that is the problematic part, so using a black-box technique on training seem like a wasteful decision. Back to the past, I was in high (or middle? I don’t really remember it well) school programming games with OpenGL and just came across this legendary video series of 3Blue1Brown, which actually explained in detail what a neural network is and how to train it using a more up-to-date method, Backpropagation and Gradient Descent. I did not quite understand the math back then, but once I nailed down high school calculus, it all made sense to me.
Before entering university, I decided to put my knowledge of Calculus to good use and tried to program a simple MNIST digit classifier program, as a warm-up (back then, I thought university classes would teach more impressive stuff than I thought, and being able to program a simple ML demo should be a minimum entry point). Then, I arrived at a roadblock. I couldn’t figure out the math for the matrix operations. I had a good sense for Linear Algebra thanks for 3Blue1Brown’s series, but I just could not derive the math. Back then, all I know about matrix multiplication was just “oh matrix multiplication is just linear map composition”, and I had no experience of actually doing the computation. Unlike a sensible undergrad who add indices to everything an reduce the problem to a scalar one, I took the harder approach and attempt to study matrix calculus. There, I found an amazing lecture notes PDF by Joseph Breen on Advanced Multivariable Differential Calculus. Back then, you can search the file on Google and find a link, but it seems like they deleted it.
After studying everything in that PDF, I became obsessed with the concept of the Fréchet derivative, which is a generalization of a derivative in normed vector spaces. It basically changed my mind on what’s really a derivative. The rate-of-change intuition makes sense in scalar space \(\mathbb{R}\), but it broke down completely in higher-dimensional spaces, where vector division no longer makes sense.
Before continuing, I advise you to study up on basic Linear Algebra and Calculus (multivariate, preferably), as well as getting a good sense of what Backpropagation actually do under the hood. You don’t have the know the algebraic techniques of finding limits and solve linear equations, just a good sense of intuition is fine.
So, what’s the proper way to represent the derivative?
Given a function \(f: V \to W\) that maps from a normed vector space \(V\) to another normed vector space \(W\). Wait, what is a normed vector space?
A vector space is simply a space of vector-like objects. Head to Wikipedia for the rigorous definition, but here I will just explain it intuitvely. Vector-like objects are object you can:
- add (or subtract) with a vector-like object of the same “type” (in the same space), or
- multiply with a scalar, i.e. a real number,
in a way that preserves some sensible conditions (associativity, commutativity, distributivity, etc.).
Then,
- \(\mathbb{R}\), the set of real numbers is a vector-space.
- \(\mathbb{R^{n}}\), the set of \(n\)-dimensional vectors is also a vector-space.
- \(\mathbb{R^{m \times n}}\), the set of \(m \times n\)-dimensional matrices is yet another vector-space.
Now, if we add some division operation to our definition above, everything completely broke down. There is just no conventional way to divide vectors or even matrices.
Next, we define a norm as a measure of distance from some origin (the zero vector), denoted as \(\|\cdot\|\), such that:
- Norm of a vector must be always non-negative: \( \|\mathbf{v}\| \ge 0 \). Moreover, equality only holds if \( \mathbf{v} \) is 0-distance away from the origin, i.e. \( \mathbf{v} \) is the origin itself.
- The triangle inequality holds: \( \|\mathbf{v} + \mathbf{w}\| \le \|\mathbf{v}\| + \|\mathbf{w}\| \).
- Scaling a vector also scale its norm: \( \|k \cdot \mathbf{v}\| = |k| \cdot \|\mathbf{v}\| \).
Then, a normed vector space is just a vector space with a defined norm. With that out of the way, we can go back to the definition.
Given a function \(f: V \to W\) that maps from a normed vector space \(V\) to another normed vector space \(W\) and a point \( \mathbf{v} \in V \). Then, a linear map \( L: V \to W \) is called the (Fréchet) derivative of \( f \) at \( \mathbf{v} \) iff this limit exists and holds:
\[ \lim_{d \mathbf{v} \to 0} \frac{\|f(\mathbf{v} + d \mathbf{v}) - f(\mathbf{v}) - L(d \mathbf{v})\|}{\|d \mathbf{v}\|} = 0. \]Here, \( d \mathbf{v} \) is just another variable, which might look confusing, but this notation will be useful later on.
When I say \( L \) is a linear map, it means that you can do stuff like \( L(\mathbf{x} + \mathbf{y}) = L(\mathbf{x}) + L(\mathbf{y}) \) and \( L(k \mathbf{x}) = k L(\mathbf{x}) \). So \( L(d \mathbf{v}) = f(\mathbf{v} + d \mathbf{v}) - f(\mathbf{v}) \), even though it satisfies the limit condition, is not a valid derivative (in most cases).
Now, the derivative of a function is a function. Moreover, it’s the same kind of function as the original one! Why is it this way?
The limit basically says that the numerator approaches 0 faster than \( d \mathbf{v} \), which means \( f(\mathbf{v}) + L(d \mathbf{v}) \) is very good at approximating \( f(\mathbf{v} + d \mathbf{v}) \) (for small \( d \mathbf{v} \)). In other words, when you zoom in the graph of \( f \) at \( \mathbf{v} \), the graph will resemble that of \( L \) (at anywhere, since \( L \) is linear).
If we denote \( d f = f(\mathbf{v} + d \mathbf{v}) - f(\mathbf{v}) \), then \( d f \approx L(d \mathbf{v}) \). \( L \) is the linear approximation to \( df \), which can be thought of as the change in \( f \) when one add a small amount \( d \mathbf{v} \) to \( \mathbf{v} \).
So, we replace the rate of change by the linear approximation of change. It does make sense, if we have the rate of change, we can construct the linear approximation, but the rate of change is not defined in higher-dimensional spaces. The Fréchet derivative solved this problem.
Some basic results of Fréchet derivative
When you look at my wordings, you might realize that I’m calling \( L \) the derivative, not a derivative. This suggests that \( L \) is unique, in the sense that if \( K \) and \( L \) are derivatives of \( f \) at \( \mathbf{v} \), then \( K(d \mathbf{v}) = L(d \mathbf{v}) \) for all \( d \mathbf{v} \).
Let’s prove it, shall we?
Using the triangle inequality, we have:
\[ \begin{align*} 0 \le \frac{\|K(d \mathbf{v}) - L(d \mathbf{v})\|}{\|d \mathbf{v}\|} &\le \frac{\|f(\mathbf{v} + d \mathbf{v}) - f(\mathbf{v}) - K(d \mathbf{v})\|}{\|d \mathbf{v}\|}\\ &+\frac{\|f(\mathbf{v} + d \mathbf{v}) - f(\mathbf{v}) - L(d \mathbf{v})\|}{\|d \mathbf{v}\|} \end{align*} \]By the squeeze theorem, we must have:
\[ \lim_{d \mathbf{v} \to 0} \frac{\|K(d \mathbf{v}) - L(d \mathbf{v})\|}{\|d \mathbf{v}\|} = 0. \]Taking the partial limit as \( d \mathbf{v} = t \mathbf{u}, t \to 0^+, \mathbf{u} \neq 0 \), we have:
\[ \begin{align*} 0 &= \lim_{d \mathbf{v} \to 0} \frac{\|K(d \mathbf{v}) - L(d \mathbf{v})\|}{\|d \mathbf{v}\|}\\ &= \lim_{t \to 0} \frac{K(t \mathbf{u}) - L(t \mathbf{u})}{\|t \mathbf{u}\|}\\ &= \lim_{t \to 0} \frac{t K(\mathbf{u}) - t L(\mathbf{u})}{t \|\mathbf{u}\|}\\ &= \frac{K(\mathbf{u}) - L(\mathbf{u})}{\|\mathbf{u}\|} \end{align*} \]This must mean \( K(\mathbf{u}) = L(\mathbf{u}) \). And this holds for all \( \mathbf{u} \). Therefore \( K = L \).
With uniqueness out of the way, we continue with linearity. If \( K \) and \( L \) are derivatives of \( f \) and \( g \) at \( x \), respectively, then \( \alpha K + \beta L \) is the derivative of \( \alpha f + \beta g \) at \( x \). Once again, the proof utilize triangle inequality and the squeeze theorem:
\[ \begin{align*} 0 &\le \frac{\| (\alpha f + \beta g)(\mathbf{x} + d \mathbf{x}) - (\alpha f + \beta g)(\mathbf{x}) - (\alpha K + \beta L)(d \mathbf{x}) \|}{\|d \mathbf{x}\|}\\ &= \frac{\| \alpha (f(\mathbf{x} + d \mathbf{x}) - f(\mathbf{x}) - K(d \mathbf{x}))+ \beta (g(\mathbf{x} + d \mathbf{x}) - g(\mathbf{x}) - L(d \mathbf{x})) \|} {\|d \mathbf{x} \|}\\ &\le |\alpha| \cdot \frac{\|f(\mathbf{x} + d \mathbf{x}) - f(\mathbf{x}) - K(d \mathbf{x})\|}{\|d \mathbf{x}\|} + |\beta| \cdot \frac{\|g(\mathbf{x} + d \mathbf{x}) - g(\mathbf{x}) - L(d \mathbf{x})\|}{\|d \mathbf{x}\|}\\ & \to 0, \text{as } d \mathbf{x} \to 0 \end{align*} \]Another important result is the derivative of linear and constant maps.
- If \( f \) is linear, than its derivative at anywhere is itself. Remember our attept at letting \( L(d \mathbf{v}) = f(\mathbf{v} + d \mathbf{v}) - f(\mathbf{v}) \) above? It turns out that when \( f \) is linear, we can expand \( f(\mathbf{v} + d\mathbf{v}) = f(\mathbf{v}) + f(d\mathbf{v}) \), yielding \( L(d \mathbf{v}) = f(d\mathbf{v}) \).
- If \( f \) is constant, than its derivative is the zero map. This should be easy to show, both intuitively and rigorously.
Using linearity of derivatives, we can find the derivative of any affine map, i.e. the sum of a constant map and a linear map.
This might seem trivial, but I was truly shocked once I realize operations like trace (\( \operatorname{tr} \)) and transpose are (\( \cdot^T \)) are linear. It turns out that those operations actually belong to the easiest class of operations to differentiate!
The heart of Backpropagation: the Chain Rule
In Calculus, the Chain Rule is probably one of the most differentiation rules. It let us find the derivative of a composite function, which effectively allow us to differentiate any function.
For Backpropagation, the Chain Rule is oftenly considered the heart of this algorithm. Backpropagation operates on multi-layer perceptrons, which could be thought of as the composition of multiple much simpler functions.
Hence, we need a Chain Rule for Fréchet differentiation. Its statement is as follows.
Given functions \( f: U \to V, g: V \to W \) with \( U, V \) and \( W \) being normed vector spaces. For some \( \mathbf{x} \in U \), if \( K \) is the derivative of \( f \) at \( \mathbf{x} \), \( L \) is the derivative of \( g \) at \( f(\mathbf{x}) \), then the composition of \( L \) and \( K \),
\[ M(d \mathbf{x}) = L(K(d \mathbf{x})), \]is in fact the derivative of \( h(\mathbf{x}) = g(f(\mathbf{x})) \) at \( \mathbf{x} \), assuming that \( K \) and \( L \) is bounded.
\( L \) being a bounded linear map means that \( \|L(\mathbf{x})\| \) is always bounded by \( \alpha \| \mathbf{x} \|\), with \( \alpha \) being some globally chosen constant (\( alpha \) does not depend on \( \mathbf{x} \)). If the domain and codomain of a linear map is finite-dimensional, then it is bounded. Since all norms are equivalent (this is a pretty complicated result), we just need to prove this result for a specific norm. Here, I will prove it for the Euclidean norm.
Let \( \mathbf{e}_1, \mathbf{e}_2, ..., \mathbf{e}_k\) be an arbitrary basis of the domain vector space, then for every vector \(\mathbf{x}\), we can write \( \mathbf{x} = \sum_{k=1}^n x_k \mathbf{e}_k \), then \( \|L(\mathbf{x})\| \le \sum_{k=1}^n |x_k| \|L(\mathbf{e}_k)\| \le \|\mathbf{x}\| \sum_{k=1}^n \|L(\mathbf{e}_k)\| \). Hence, it suffices to just let \( \alpha = \sum_{k=1}^n \|L(\mathbf{e}_k)\| \). Note that this value of \( \alpha \) only depends on the basis that we can freely choose.
With boundedness out of the way, we start with the proof. We need to prove:
\[ \lim_{d \mathbf{x} \to 0} \frac{\|h(\mathbf{x} + d\mathbf{x}) - h(\mathbf{x}) - M(d\mathbf{x})\|}{\|d\mathbf{x}\|} = 0. \]Let’s look at the numerator:
\[ \begin{align*} &h(\mathbf{x} + d\mathbf{x}) - h(\mathbf{x}) - M(d\mathbf{x})\\ &= (g(f(\mathbf{x} + d\mathbf{x})) - g(f(\mathbf{x})) - L(f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x})) ) + L(f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x}) - K(d\mathbf{x}))\\ &= (g(f(\mathbf{x}) + df) - g(\mathbf{x}) - L(df)) + L(f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x}) - K(d\mathbf{x})), \end{align*} \]where \( df = f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x}) \).
Using the triangle inequality and the squeeze theorem, the problem reduces to proving:
\[ \lim_{d\mathbf{x} \to 0} \frac{\|g(f(\mathbf{x}) + df) - g(\mathbf{x}) - L(df)\|}{\|d\mathbf{x}\|} = 0, \]and,
\[ \lim_{d\mathbf{x} \to 0} \frac{\|L(f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x}) - K(d\mathbf{x})\|}{\|d\mathbf{x}\|} = 0. \]The first limit can be split to:
\[ \lim_{d\mathbf{x} \to 0} \left( \frac{\|g(f(\mathbf{x}) + df) - g(\mathbf{x}) - L(df)\|}{\|df\|}\cdot \frac{\|df\|}{\|d\mathbf{x}\|} \right) = 0 \]The first term converges since \( df \to 0 \) when \( d\mathbf{x} \to 0 \) (why?), and the second term is bounded:
\[ 0 \le \frac{\|df\|}{\|d\mathbf x\|} \le \frac{\|f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x}) - K(d\mathbf x)\|}{\|d\mathbf{x}\|} + \frac{\|K(d\mathbf x)\|}{\|d\mathbf x\|}. \]The second limit can be split to:
\[ \lim_{d\mathbf{x} \to 0} \left(\frac{\|L(d f) - K(d\mathbf{x))\|}{\|d f - K(d\mathbf{x})\|}\cdot\frac{\|f(\mathbf{x} + d\mathbf{x}) - f(\mathbf{x}) - K(d\mathbf{x})\|}{\|d\mathbf{x}\|}\right) = 0. \]The second term clearly converges, while the first is bounded since \( L \) is bounded and \( df -K(d\mathbf x) \to 0 \) as \( d\mathbf x \to 0 \).
Phew, we are finally done.
Total derivative and partial derivatives.
When we work with derivatives, working with linear maps directly is clunky, so we will use total derivative notation to get around that.
Instead of working with functions like \( f \) and \( L \), we will talk about quantities. Quantities form some form of dependency tree, like so:
\[ w = y^2 z, y = 2x, z = x^2. \]The “leaf node” of such tree can be changed freely, while other quantity must change based on its dependency. The \( d \) operator is used to denote the change amount of a quantity.
If \( dx \) is how much \( x \) changes, then we can easily calculate \( dy, dz, dw \):
\[ dy = 2dx, dz = 2xdx, dw = 16x^3dx. \]As you can see, this not only depends on \( dx \), but also the current value of \( x \) itself. In general, change amount depends on the base change amounts and the current value of the quantities.
Using this notation, it is very easy to apply the chain rule:
\( dw = d(y^2 z) = d(y^2) z + y^2 dz = 2y\, dy\, z + y^2\, dz = 4x\cdot 2dx\cdot x^2 + (2x)^2\cdot 2x = 16x^3 dx. \)
Here, I cheated and used the product rule. Well, that’s the second topic of this part.
Given a function \( f: V \to W \) with derivative \( df \) at some \( x \in V \), and the problem is finding \( df \). To know how a linear map behave, a straightforward way is to see how it acts on some basis of its domain.
Let me rephrase it a little bit differently. Consider a variable quantity \( \mathbf{x} \) and \( n \) quantities that depend on it: \( \mathbf{y}_1, \mathbf{y}_2, \ldots , \mathbf{y}_n \). Finally, we combined everything into some sort of “super quantity”: \( \mathbf{z} = f(\mathbf{y}_1, \mathbf{y}_2, \ldots , \mathbf{y}_n) \). Now, the problem is to find the derivative of \( \mathbf{z} \) with respect to \( \mathbf{x} \).
\( f \) is a function that maps \( n \) vectors to a singular vector, you can always group all \( n \) vectors into a single “supervector” and define some form of norm on that “supervector” space. Then, \( f \) is a mapping from a normed vector space to another, and \( df \) is now a well-defined concept.
A way to do this is to fix some \( i \) and let \( d\mathbf{y}_k = 0 \) for all \( k \neq i \). Then, \( f \) collapses into a simpler map \( g \) whose only variable is \( \mathbf{y}_i \). Assuming that we can find the derivative \( dg \) of \( g \), which is oftenly written as \( \frac{\partial f}{\partial \mathbf{y}_i} \) in standard Calculus, then what we just did is finding how \( df \) act on certain basis with respect to \( d\mathbf{y}_i \). Doing the same process for other values for \( i \) yields:
\[ df = \sum_{i = 1}^n \frac{\partial f}{\partial \mathbf{y}_i} (d\mathbf{y}_i). \]Now, how do we find this partial derivative? It’s simple: just treat everything other than \( \mathbf{y}_i \) a constant. For example, consider the problem of differentiating \( x^2 \) with respect to \( x \). We will write the problem as:
\[ y = z = x, w = yz. \]Then, \( dy = dz = dx \) and \( dw = \frac{\partial (yz)}{\partial y} (dy) + \frac{\partial (yz)}{\partial z} (dz). \) \( \frac{\partial(yz)}{\partial y} (dy) \) is simply \( dy \cdot z \) since \( yz \) is a linear map with respect to \( y \). This also simplifies further to \( xdx \), and so does the other term. Hence, \( d(x^2) = 2xdx \).
Note that we did not use any knowledge of the power rule or anything similar in finding the derivative of \( x^2 \). However, we did make a vital assumption that the derivative itself exists. For this example, this can be easily verified by plugging back \( 2xdx \) to the original definition, but this is not a general way to handle these circumstances. ML don’t really care about the nitty-gritty details of the derivative, since they pretend stuff like \( \operatorname{relu} \) are differentiable anywhere, but if we want to be rigorous, we need to be vary of that. There is, however, an useful result you can use for proving the existence of derivative:
Theorem: If all partial derivatives of a function exists and is continuous in a neighborhood of a point \( \mathbf{x} \), then that function has a derivative at \( \mathbf{x} \).
Derivative of the squared Frobenius norm
Now, we will utilize everything we proved above in this elegant result.
The squared Frobenius norm of a \( m \times n \) matrix is defined as:
\[ \|M\|^2 = \sum_{k = 1}^m \sum_{l = 1}^n M_{kl}^2 \]This is a generalization of the squared Euclidean norm, which arises in loss functions like the mean squared error. Hence, it is something we would like to calculate the derivative of.
Doing it component-wise would be no fun, so let’s write \( \|M\|^2 \) as:
\[ \|M\|^2 = \operatorname{tr}(M^T M). \]Let use the \( d \) operator. Since trace is linear, we can just pass it right through:
\[ d(\|M\|^2) = d(\operatorname{tr}(M^T M)) = \operatorname{tr}(d(M^T M)). \]Now, we need to solve for the derivative of \( d(M^T M) \). We simply use the same trick when we differentiate \( x^2 \), but with a more concise notation:
\[ d(M^T M) = d(M^T) M + M^T dM = dM^T M + M^T dM. \]Once again, \( d \) propagates through \( \cdot^T \) since the latter is linear. I hope that now you have seen how powerful linearity is.
Note, however, that I’m not switching terms around due to the fact that matrix multiplication is not commutative. When we use the fact that the derivative of a linear map is itself, we must keep that linear map exactly the same.
However, we notice that everything is wrapped inside a trace operation. And fun fact: \( \operatorname{tr}(A) = \operatorname{tr}(A^T) \). By pure coincidence, the two terms in the final sum is actually each other’s transpose!
\[ (M^T dM)^T = dM^T (M^T)^T = dM^T M. \]Finally, we have:
\[ \begin{align*} d(\|M\|^2) &= \operatorname{tr}(dM^T M + M^T dM) = \operatorname{tr}(dM^T M) + \operatorname{tr}(M^T dM)\\ &= 2\operatorname{tr}(M^T dM) = 2\operatorname{tr}(dM^T M). \end{align*} \]There you go, that’s the derivative of the squared Frobenius norm. It does not look like something multiplied with \( dM \), but that’s just a limitation of matrices: matrix multiplication could only represent linear maps on vectors, not matrices. In fact, such a result could not even exist (in non-trivial cases). If we can write \( d(\|M\|^2) = X d M \), then looking at the dimensions, there is an immediate paradox. If \( M \) is \( m \times n \)-dimensional, then the matrix multiplication must yield some \( \ldots \times n \)-dimensional matrix, and not a scalar!
Also, for those wondering that why aren’t we finding the derivative for the Frobenius norm itself. I have two reasons for that:
- It’s more complicated due to the addition of the square-root operation.
- The Frobenius norm is usually used to describe some form of error. And minimizing that error is the same as minimizing the error squared. Hence, differentiating the squared Frobenius norm is a far more pleasant experience that does the exact same job.
Conclusion
So that’s it for the first part of this blog series. Without having to resort to indices, we have developed a new theory for differentiation that works on all sort of vectors (not just the usual \( \mathbb{R}^n \)). Also, I think this should be stated sooner, I just could not find the space to, but this theory is based on that amazing lecture notes PDF. The total derivative is kind of invented by me (it’s probably the result of me looking at similar notations and finally getting a sense of that, to be honest). In the process, we have also discovered an ugly truth: not all derivatives can be represented using a clear and concise form like the Jacobian matrix, as demonstrated above. And of course, treating those derivatives directly as function objects while implementing NN algorithms would be a direct path towards poor performance (I don’t even think it’s possible, considering the weights and whatnot).
Also, in this blog, there is a huge time skip. I learned about the Fréchet derivative while I was a freshman (or even before), but I could only find the derivative of the squared Frobenius norm just until recently (of course my freshman self could cheese it using indices, but you know what I mean). I just came back to this problem after neglecting it for a long while, after all.
In the next part, I think we will derive the math of Backpropagation on Multilayer Perceptrons. It was yet another failed attempt of mine on training a handwritten digit recognizer.
